Mikrotik CCR1009-8G-1S-1S+PC Firewall Router
Bu ürünün üretimi durdurulmuş olup yeni seri modeli - CCR1009-7G-1C-1S+ olarak satışa devam etmektedir.
Önceki Versiyon
CCR1009-8G-1S+PC | 6Gbps |
CCR1009-8G-1S-1S+PC | 16Gbps |
CCR1009-8G-1S-1S+ | 16Gbps |
Yeni Versiyon
8Gbps | |
18Gbps | |
18Gbps |
Specifications
| Details | |
|---|---|
| Product code | CCR1009-8G-1S-1S+PC |
| Architecture | TILE |
| CPU | TLR4-00980 |
| CPU core count | 9 |
| CPU nominal frequency | 1 GHz |
| Switch chip model | AR8327-BL1A-R |
| Dimensions | 272x190x47mm |
| RouterOS license | 6 |
| Operating System | RouterOS |
| Size of RAM | 2 GB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -20°C to 60°C |
Powering
| Details | |
|---|---|
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 14-57 V |
| Max power consumption | 30 W |
| Max power consumption without attachments | 30W |
| Cooling type | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 14-57 V |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 8 |
Fiber
| Details | |
|---|---|
| SFP ports | 1 |
| SFP+ ports | 1 |
Peripherals
| Details | |
|---|---|
| Number of SIM slots | 1 Smart card (Mini SIM) |
| Serial console port | RS232 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | microUSB type AB |
| Max USB current (A) | 1 |
Other
| Details | |
|---|---|
| CPU temperature monitor | Yes |
| Current Monitor | Yes |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Beeper | Yes |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
Ethernet test results
|
CCR1009-8G-1S-1S+PC |
Tile 9 core all port test with SFP+ |
||||||
|
Mode |
Configuration |
1518 byte |
512 byte |
64 byte |
|||
|
kpps |
Mbps |
kpps |
Mbps |
kpps |
Mbps |
||
|
Bridging |
none (fast path) |
974.0 |
11,828.3 |
2,817.0 |
11,538.4 |
10,491.1 |
5,371.4 |
|
Bridging |
25 bridge filter rules |
974.0 |
11,828.3 |
1,390.0 |
5,693.4 |
1,447.6 |
741.2 |
|
Routing |
none (fast path) |
974.0 |
11,828.3 |
2,817.0 |
11,538.4 |
8,217.1 |
4,207.2 |
|
Routing |
25 simple queues |
974.0 |
11,828.3 |
1,803.0 |
7,385.1 |
1,947.2 |
997.0 |
|
Routing |
25 ip filter rules |
680.4 |
8,262.8 |
870.1 |
3,563.9 |
878.7 |
449.9 |
- All tests are done with Xena Networks specialized
test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second
attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet
sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
