MikroTik hAP AC² - RBD52G-5HacD2HnD-TC Dualband Router Firewall Hotspot , 716Mhz 32bit ARm işlemci, 128 MB Ram, 2x2 Mimo 600mW 2.4 GHz 802.11b/g/n radyo kartı ve 2x2 Mimo 802.11ac 450mW 5 GHz radyo kartı ile Küçük ve orta ölçekli işletmelerin, Ev kullanıcılarının, Hotellerin veya Kablosuz internet servis sağlayıcıların(WISP) son kullanıcı tarafındaki ihtiyaçlarını karşılamak amacı ile performas ve maliyet ön planda tutularak , hepsi bir arada tasarım anlayışı ile üretilmiştir.
Ayrıca cihaz üzerinde bulunan USB portuna bağlayacağınız 3G / LTE USB modemler ile hat yedekleme yapılabilir ya da bağladığınız harici disk veya USB Flash diskinizi ağ üzerinde dosya sunucusu olarak kullanabilirsiniz. Bu özelliklerin yanısıra ürünün  5' inci ethernet portu 24 Volt PoE çıkışı verebiliyor, bu özellik sayesinde PoE destekli cihazlarınızı ilave adaptör kullanmadan çalıştırabilirsiniz.

Specifications

Details
Product code	RBD52G-5HacD2HnD-TC
Architecture	ARM 32bit
CPU	IPQ-4018
CPU core count	4
CPU nominal frequency	716 MHz
Switch chip model	IPQ-4018
Dimensions	34 x 119 x 98mm
RouterOS license	4
Operating System	RouterOS
Size of RAM	128 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 100'000 hours at 25C
Tested ambient temperature	-40°C to 50°C
IPsec hardware acceleration	Yes

Wireless capabilities

Details
Wireless 2.4 GHz Max data rate	300 Mbit/s
Wireless 2.4 GHz number of chains	2
Wireless 2.4 GHz standards	802.11b/g/n
Antenna gain dBi for 2.4 GHz	2.5
Wireless 2.4 GHz chip model	IPQ-4018
Wireless 2.4 GHz generation	Wi-Fi 4
Wireless 5 GHz Max data rate	867 Mbit/s
Wireless 5 GHz number of chains	2
Wireless 5 GHz standards	802.11a/n/ac
Antenna gain dBi for 5 GHz	2.5
Wireless 5 GHz chip model	IPQ-4018
Wireless 5 GHz generation	Wi-Fi 5
WiFi speed	AC1200

Ethernet

Details
10/100/1000 Ethernet ports	5

Peripherals

Details
Number of USB ports	1
USB Power Reset	Yes
USB slot type	USB type A
Max USB current (A)	1

Powering

Details
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	12-30 V
Max power consumption	21 W
Max power consumption without attachments	16 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	18-28 V

Certification & Approvals

Details
Certification	CE, FCC, IC, EAC, ROHS
IP	IP20

Other

Details
Mode button	Yes

Wireless specifications

2.4 GHz	Transmit (dBm)	Receive Sensitivity
1MBit/s	27	-100
11MBit/s	27	-94
6MBit/s	27	-96
54MBit/s	24	-78
MCS0	27	-96
MCS7	23	-73

5 GHz	Transmit (dBm)	Receive Sensitivity
6MBit/s	26	-96
54MBit/s	22	-80
MCS0	26	-96
MCS7	21	-75
MCS9	19	-70

Ethernet test results

RBD52G-5HacD2HnD-TCr2		IPQ-4018 1G all port test
Mode	Configuration	1518 byte		512 byte		64 byte
		kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	162.5	1973.4	469.9	1924.7	1484.8	760.2
Bridging	25 bridge filter rules	162.1	1968.5	352.9	1445.5	359.2	183.9
Routing	none (fast path)	162.5	1973.4	469.9	1924.7	1488	761.9
Routing	25 simple queues	162.5	1973.4	469.9	1924.7	506.3	259.2
Routing	25 ip filter rules	162.2	1969.8	240.8	986.3	242.9	124.4

1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

IPsec test results

RBD52G-5HacD2HnD-TCr2		IPQ-4018 IPsec throughput
Mode	Configuration	1400 byte		512 byte		64 byte
		kpps	Mbps	kpps	Mbps	kpps	Mbps
Single tunnel	AES-128-CBC + SHA1	37.9	424.5	59	241.7	61.6	31.5
256 tunnels	AES-128-CBC + SHA1	36	403.2	38.5	157.7	39.8	20.4
256 tunnels	AES-128-CBC + SHA256	36	403.2	38.5	157.7	39.8	20.4
256 tunnels	AES-256-CBC + SHA1	34.4	385.3	37.9	155.2	39.8	20.4
256 tunnels	AES-256-CBC + SHA256	34.4	385.3	37.9	155.2	39.8	20.4

1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
