Mikrotik CRS309-1G-8SPLUS-IN 8 Port SFP+ Yönetilebilir Switch

(0 Yorumlar)
Marka
Mikrotik

Şirket içi ürün


Fiyat
$276.00 /KDV Dahil
Miktar
(0 mevcut)
Toplam fiyat
Specifications
Paylaş

Reviews & Ratings

0 out of 5.0
(0 Yorumlar)
Bu ürün için henüz bir inceleme yapılmamıştır.

Mikrotik CRS309-1G-8S+IN

CRS309-1G-8S + çok kompakt ve güçlü bir Switch'tir. Destekleyen 8 SFP + yuvası vardır

Her birinde 10 Gbit'e kadar olan modül, toplam 162 Gbps switching kapasitesine sahiptir ve non-blocking throughput değeri 81 Gbpstir.





Cihaz ayrıca çift çekirdekli 800 MHz CPU'ya, 512 MB RAM'e ve PoE-in özelliğine sahip bir yönetim Ethernet portuna sahiptir.

RS232 seri port, topraklama terminali ve çift önyükleme özelliğine sahiptir

RouterOS veya SwOS işletim sistemlerinden birini tercih edebilirsiniz.





Kompakt ve şık metalik muhafaza aynı zamanda soğutucu olarak da işlev görür ve bu cihazı pasif olarak soğutur.

Fan gürültüsü yoktur ve içerisinde toz birikmez. Kabine monte etmek için özel raf kulakları

bulunmaktadır.

Specifications

Details
Product codeCRS309-1G-8S+IN
ArchitectureARM 32bit
CPU98DX8208
CPU core count2
CPU nominal frequency800 MHz
Switch chip model98DX8208
Dimensions272 x 191 x 44 mm
RouterOS license5
Operating SystemRouterOS / SwitchOS
Size of RAM512 MB
Storage size16 MB
Storage typeFLASH
MTBFApproximately 200'000 hours at 25C
Tested ambient temperature-40°C to 70°C


Powering

Details
Number of DC inputs2 (PoE-IN, DC jack)
DC jack input Voltage12-57 V
Max power consumption23 W
Max power consumption without attachments17 W
Cooling typePassive
PoE in802.3af/at
PoE in input Voltage18-57 V

Ethernet

Details
10/100/1000 Ethernet ports1

Fiber

Details
SFP+ ports8

Peripherals

Details
Serial console portRS232

Other

Details
CPU temperature monitorYes
BeeperYes

Certification & Approvals

Details
CertificationCE, EAC, ROHS
IPIP20

Switching results

CRS309-1G-8S+IN
ModeConfiguration1518 byte512 byte64 byte
kppsMbpskppsMbpskppsMbps
SwitchingNon blocking Layer 2 throughput6,583.279,946.719,032.077,954.9120,535.761,714.3
SwitchingNon blocking Layer 2 capacity6,583.2159,893.419,032.0155,909.8120,535.7123,428.6
SwitchingNon blocking Layer 1 throughput6,583.281,000.019,032.081,000.0120,535.781,000.0
SwitchingNon blocking Layer 1 capacity6,583.2162,000.019,032.0162,000.0120,535.7162,000.0

Ethernet test results

CRS309-1G-8S+IN98DX8208 all port test
ModeConfiguration1518 byte512 byte64 byte
kppsMbpskppsMbpskppsMbps
Bridgingnone (fast path)217,52641.3231,1946.6243,6124.7
Bridging25 bridge filter rules117,41425.7117,4480.9145,274.3
Routingnone (fast path)207,62521.1217,6891.3229,5117.5
Routing25 simple queues121,11470.6122,7502.6145,274.3
Routing25 ip filter rules83,61015.283,1340.488,945.5
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
